Hayes Mechanical provides boiler upgrade to Belmont Harbor Condo building

May 11, 2017
The 20-unit condo building's water heater was deteriorating rapidly and the boiler old and inefficient. Chicago-based Hayes Mechanical installed a new, advanced condensing boiler product: the 96.5 percent AFUE Evergreen 399 MBH boiler from Weil-McLain.  After experiencing an entire winter with the new system installed, the facility realized a total fuel savings of 42 percent.
Chicago-based Hayes Mechanical was selected to handle the heating upgrade at the 20-unit Belmont Harbor condo building. Hayes has handled repairs to the building’s HVAC system for years.

CHICAGO — With a rapidly failing water heater and an old inefficient boiler, a 20-unit condominium building required major upgrades to its heating system.

“Our water heater was deteriorating rapidly and our boiler very old and inefficient,” said Mike Nowak, president of the board for the Belmont Harbor Condominium, a three story, 20-unit building on Chicago’s north side.

The building’s heating system featured a one million BTU boiler operated via an outdoor reset control and a 400,000 BTU/hr direct water heater with a 100 gallon storage tank. The individual condo units are heated by hot water baseboard heaters.

“The skin of the water heater was melting and deforming, and the unit was leaking,” said Nowak. “It also caused the boiler room to become extremely warm because the unit was always on and not venting properly.”

The aging boiler also was failing and required regular maintenance.

“The boiler was way past its expected life, and the heat output very inefficient,” said Nowak. “It operated continuously, especially if it was less than 56 degrees outdoors.”

Nowak added that some residents complained about excessive heat, especially those who lived above the boiler room area. Others complained about not having enough hot water.

Installation upgrade

Hayes Mechanical installed two 96.5 percent AFUE Evergreen 399 MBH boiler from Weil-McLain. The condensing boilers were installed as a Multiple Boiler System using a Modbus communication feature.

Chicago-based Hayes Mechanical, who handled repairs to the building’s HVAC system for years, was selected to handle the heating upgrade. The third-generation plumbing/heating contractor was founded in 1918. After being acquired by Consolidated Engineering in 2000 (which was in turn purchased by EMCOR), the Mooney/Hayes family purchased the company back in 2005 and re-launched with a new executive management team.

The Belmont Harbor Condominium project began in mid-November 2015. Hayes Mechanical proceeded to install a new, advanced condensing boiler product: the 96.5 percent AFUE Evergreen 399 MBH boiler from Weil-McLain. The Evergreen features advanced technology with simple controls, flexible functionality for multiple applications and a durable design, and is easy to install, use and maintain.

The unit is adaptable for most heating needs including light commercial or large residential applications and for single or multi-boiler installations.

The two Evergreen boilers were installed as a Multiple Boiler System (MBS) using a Modbus communication feature. In this lead-lag configuration, a master boiler controls the modulation and sequencing of boilers on the network to achieve the desired system supply temperature.

According to the installing technician with Hayes Mechanical, with the automatic sequencing feature, the boilers communicate directly with one another, so they sequence themselves and rotate as needed. Both operate at the lowest rate to optimize efficiencies, and they function with a built-in controller so no additional controls are needed.

The upgrade also included the installation of two Weil-McLain 80-gal. Aqua Plus indirect-fired waters heaters to replace the existing direct-fired water heater and storage tank.

The Aqua Plus units feature high output stainless steel heat exchangers that deliver superior first hour ratings and recovery. The units’ compact size allows for easy installation in low ceiling basements or storage rooms, and thermostat connections are already installed for quick wiring.

One of Nowak’s concerns early on was the interruption of hot water for tenants. Hayes Mechanical made sure access to domestic hot water was only out for several hours one day in the beginning of the project.

In addition to installing the new, advanced systems, Hayes Mechanical upgraded all of the boiler room piping — including the boiler connections, indirect fired water heaters and the supply and return — with stainless steel pipes.

“The installation progressed smoothly with limited interruption to building occupants,” said Nowak. “Weil-McLain had an engineer who came out to advise us, answer our questions and to conduct diagnostic testing to ensure everything was in order.”

Upgrade benefits

After experiencing an entire winter with the new system installed, the facility realized a total fuel savings of 42 percent.

Both Nowak and residents of the Belmont Harbor building have experienced several benefits from the new system.

“The heat is very comfortable and building occupants are happy about that and appreciative of the ample supply of hot water now available,” said Nowak.

Nowak also was pleased with the project timeline and management.

“Throughout the project, the Weil-McLain and Hayes Mechanical teams ensured everything was delivered on time and everyone was on top of their to-do lists,” said Nowak.

The most important benefit: after experiencing an entire winter with the new system installed, the facility realized a total fuel savings of 42 percent.

“Even if we bump up the heat a little, our bills don’t really change that much,” added Nowak. “It really is a phenomenal, efficient system and the energy savings have been fantastic.”
